Mechanic MOS 300 Stereo Trinocular Microscope 6-45X with B11 Big Base (Black Edition)

Mechanic MOS 300 Trinocular Microscope 6-45X for Precision Repair

The Mechanic MOS 300 is a professional-grade stereo trinocular microscope designed for precision tasks like PCB repair, soldering, and microelectronics inspection. Featuring 6-45X magnification, a stable B11 big base, and dual eyepiece/camera output, it ensures high-clarity imaging for detailed work. The trinocular port supports HD camera attachment for documentation or live viewing, making it perfect for labs and repair workshops.

Features

• 6-45X Zoom Magnification – Adjustable for detailed inspection.
• Stereo & Trinocular Viewing – Dual eyepieces + camera port (C-mount compatible).
• B11 Big Base – Heavy-duty stability for vibration-free work.
• Wide Field Eyepieces (10X/20mm) – Reduced eye strain during prolonged use.
• LED Ring Light – Bright, shadow-free illumination.
• Ergonomic Design – Adjustable focus and interpupillary distance.
• Durable Metal Body – Long-lasting professional use.

Specification:

• Observation Head: 45° incline, 360° rotation, interpupillary distance 54–76mm, ±5 visual adjustment
• Eyepiece (Standard): WF10X22, high-angle wide field for glasses users
• Optional Eyepieces: WF15X15mm, WF20X10mm, WF25X9mm, WF30X8mm
• Objective Lens: 0.6X–4.5X zoom range, magnification ratio 1:10
• Auxiliary Lenses: 0.3X, 0.5X, 0.75X, 1X, 1.5X, 2X (optional)
• Magnification: Standard 6X–45X; extended 1.8X–90X with auxiliary lens
• Working Distance: 100mm
• Focus Arm: 76mm diameter, 32mm support pole
• Base Plate: Black/White reversible plate
• Base: B11 heavy-duty column base (optional upgradeable)
• Dimensions: 200mm (W) × 273mm (D) × 280mm (H)
• Illumination: Optional LED (check compatible light source series)

Applications & Compatible Work:

• Smartphone motherboard soldering (A-series, Snapdragon, MTK SoCs)
• Logic board diagnostics & rework
• CPU/BGA soldering alignment
• Micro IC inspection
• Face ID/Flex Cable tracing
• Reballing and de-oxidation assessment
• Suitable for A13, A14, A16, SM8250, MT6833, PMIC chips

FAQ Section

• Q: Is this microscope suitable for SMD rework?
• A: Yes, the 6-45X magnification and stereo vision make it ideal for SMD soldering and PCB repair.
• Q: Can I attach a camera to this microscope?
• A: Yes, the trinocular port supports camera mounting for live imaging or recording.
• Q: Does it include built-in lighting?
• A: Yes, it features adjustable LED illumination for optimal visibility.
• Q: What’s the working distance?
• A: The MOS 300 provides ample working space for tools under the lenses.

Note: Product includes the black version of the Mechanic MOS300 Trinocular Microscope. Images shown with the blue version are for reference and demonstration purposes only

Package includes:

• 1 x Trinocular microscope
• 1 x Microscope Base
• 1 x All-in-one LED ring light
• 2 x WF10X/22 eyepiece
• 2  x Goggle
• 1 x Dust mirror
• 1 x Limit block
• 1 x CTV 2/5 Adapters(only MOS300)
